Airports and major transport hubs face unique glazing challenges that go far beyond typical commercial buildings. These critical infrastructure sites require specialist glazing systems that balance security, passenger experience, and operational continuity whilst meeting stringent aviation safety standards.
Back To Blog
Airports and major transport hubs face unique glazing challenges that go far beyond typical commercial buildings. These critical infrastructure sites require specialist glazing systems that balance security, passenger experience, and operational continuity whilst meeting stringent aviation safety standards.
The UK’s Aviation Security in Airport Development (ASIAD) guidance, published by the Department for Transport since 1996, establishes comprehensive requirements for glazed elements in airport design. These standards address fire protection, visual transparency, and stand-off distances, creating a complex specification environment where safety and aesthetics must coexist.
Airport glazing differs fundamentally from standard commercial installations due to the security threat level and operational requirements. The key differentiators include:
These requirements create a specification environment where every glazing element must be engineered as a complete system rather than individual components.
Transport hubs such as railway stations, underground stations, and bus terminals face similar challenges, particularly in high-footfall urban locations where security threats and public safety concerns intersect with architectural ambitions for light, transparency, and passenger experience.
Modern airport design faces an inherent tension between security requirements and passenger experience. Travellers expect bright, welcoming spaces with views of aircraft and natural daylight, whilst security demands robust protective barriers between public areas and potential threats.
Advanced laminated glass systems resolve this tension by combining multiple layers of glass with specialised interlayer films. These systems maintain visual clarity and light transmission whilst providing comprehensive protection. The glass may appear identical to standard glazing but incorporates polyvinyl butyral (PVB) or ionoplast interlayers specifically engineered for security performance.
Dual-directional protection has become increasingly important as security professionals recognise that threats can originate from either side of a glazing system. Modern systems provide protection regardless of which side faces the threat.
Frame systems are equally critical to performance. Specialist aluminium or steel frames must anchor the glazing securely whilst allowing controlled flexing. Systems like Schüco AWS 90 XR and FW 80+ XR are tested to perform under pressure at specified distances whilst remaining visually indistinguishable from standard commercial systems. This allows architects to achieve their design intent without compromising security.
Fire safety in airports requires comprehensive protection strategies that account for the unique challenges of high-occupancy public spaces with complex evacuation requirements. Glazing systems must provide both compartmentation to prevent fire spread and safe egress routes that remain protected during evacuation.
UK Building Regulations and aviation-specific guidance require fire-resistant glazing in critical locations including:
The standard typically requires 60 to 120 minutes of fire integrity and insulation, depending on the specific application and risk assessment.
Dual-directional fire protection addresses the reality that fires can start on either side of a glazing system. Testing standards measure both integrity (preventing flame penetration) and insulation (limiting temperature rise on the non-fire side). Advanced systems using SCHOTT PYRAN or similar fire-resistant glass can deliver 120+ minutes of protection in both directions, crucial for airports where evacuation routes must remain viable regardless of where a fire originates.
Airports operate continuously with no shutdown windows for maintenance or construction, creating unique logistical challenges for glazing replacement or refurbishment projects. Unlike typical commercial buildings that can schedule work during evenings or weekends, airport glazing contractors must work around live operations whilst maintaining security protocols and minimising passenger disruption.
Phased installation programmes become essential, with work areas carefully sequenced to maintain operational capacity. Critical coordination includes:
This requires meticulous planning, with work activities coordinated around operational requirements whilst maintaining security protocols throughout.
Rope access techniques offer significant advantages in airport environments where traditional scaffolding would obstruct passenger flows or require airspace closures. IRATA-qualified technicians can access façade areas from above, working in confined sections that minimise disruption whilst maintaining rapid installation progress. This approach proves particularly valuable for terminal extensions, pier buildings, and control tower glazing where access from below is impractical.
Security clearances add complexity and timeline considerations. All operatives working airside must undergo background checks and aviation security training, with identification and access protocols strictly enforced. Materials, tools, and equipment require screening before entering secure areas, and work activities may be subject to additional restrictions during heightened security alerts.
Airport glazing systems undergo extensive testing beyond standard commercial specifications. The testing regime addresses multiple threat scenarios including:
Each test is conducted on complete assemblies rather than individual components. Testing for forced entry evaluates the glazing system’s ability to resist sustained physical attack whilst preventing hazardous fragmentation on the rear face.
Specific high-risk areas including control towers, air traffic control facilities, security posts, immigration processing, border control, executive terminals, and VIP facilities may require additional testing appropriate to their security classification.
Frame and fixing systems require independent testing to verify they can transfer impact loads to the building structure without failure. This includes pull-out testing of anchors, deflection analysis of frame members, and gasket performance under rapid pressure cycling. The complete system — glass, interlayers, frames, gaskets, and fixings — must be certified together because component interactions determine overall performance.
Rope access technology transforms airport glazing projects by enabling work in challenging locations without the airspace restrictions, operational disruption, and extended timescales associated with traditional access methods. For airport environments where conventional scaffolding would obstruct passenger flows or require runway and taxiway closures, rope access provides a viable alternative.
IRATA-certified technicians can access terminal façades, pier buildings, control towers, and atrium glazing from established anchor points on roofs or upper levels. This approach eliminates the need for extensive ground-level staging areas that would interfere with vehicle movements, passenger access, or aircraft operations. The speed of deployment — often within hours rather than weeks — allows work to proceed in narrow operational windows without disrupting flight schedules.
Safety protocols for rope access in airport environments require additional considerations beyond standard commercial projects. Operatives must avoid areas where tools or materials could fall onto aircraft, passengers, or operational zones. Work near runways or taxiways requires coordination with air traffic control and may be restricted during specific operational periods. All equipment must be secured with redundant attachment points, and drop zones must be established with appropriate exclusion barriers.
The precision of rope access techniques proves particularly valuable for surveying fire-rated glazing systems where detailed inspection of gaskets, seals, and frame integrity is essential for maintaining certification. Technicians can access individual panels for testing, maintenance, or targeted replacement without wholesale façade disruption, supporting the preventative maintenance programmes that extend system life and ensure continuous compliance with aviation safety standards.
Large glazed areas in airport terminals create significant thermal challenges that impact both passenger comfort and operational energy costs. The extensive use of glass — often spanning multiple floors in atrium designs or extending along entire terminal façades — generates substantial solar heat gain that must be managed through specification decisions and building management integration.
High-performance glazing specifications typically require solar control coatings that reduce heat transmission whilst maintaining high visible light transmission. Modern low-emissivity coatings can reject up to 70% of solar heat gain whilst allowing 60–70% of visible light through, creating bright spaces without the thermal penalty. This balance proves essential in terminals where passenger comfort, retail visibility, and energy efficiency must coexist.
Thermal bridging through frame systems represents another critical consideration. Aluminium frames, whilst offering strength and slim profiles, conduct heat readily and can create condensation problems if not thermally broken. Specialist airport glazing systems incorporate thermal breaks — typically polyamide inserts — that separate internal and external frame sections, preventing heat transfer that would compromise energy performance or create condensation that degrades seals and gaskets.
The scale of airport glazing installations means minor specification improvements yield substantial operational savings. A 10% improvement in thermal performance across a 10,000m² terminal façade can reduce HVAC loads by hundreds of kilowatts, translating to significant annual energy cost reductions. These savings often justify premium glazing specifications that would be uneconomical in smaller commercial projects.
Airport buildings contain distinct security and operational zones, each with specific glazing requirements that reflect the risk profile and functional needs of that area. The specification approach must recognise these differences whilst maintaining architectural consistency and cost-effectiveness.
Landside public areas — including check-in halls, arrivals areas, and retail concourses — require high-performance glazing on external façades. The ASIAD guidance specifies minimum stand-off distances and glazing performance levels based on threat assessments and building proximity to vehicle access points. Internal glazing may use standard specifications unless separating high-risk zones.
Airside areas face different requirements focused on operational security and controlled access. Glazing in these zones must prevent unauthorised observation of security operations, resist forced entry attempts, and maintain compartmentation between secure and non-secure areas.
Control towers represent the highest-specification zone, requiring glazing that provides unobstructed views of runways and taxiways whilst offering robust protection. These installations must eliminate visual distortion, prevent glare or reflections that could impair air traffic controllers, and maintain structural integrity under high winds. The glazing must also integrate with climate control systems that manage solar gain in all-glass structures.
Secure areas such as border control, customs examination rooms, and detention facilities require glazing that prevents communication between zones whilst maintaining visual supervision. One-way viewing glass or electronically switchable privacy glass may be specified, combined with acoustic insulation that prevents sensitive conversations being overheard. These areas often require enhanced physical security including laminated glass that resists forced entry attempts.
GLRE Manchester brings specialist capabilities to airport and transport hub glazing projects across the UK, combining technical expertise in security glazing with rope access capabilities that minimise operational disruption. Our experience spans major airports including Heathrow, Gatwick, and Stansted, plus numerous railway stations and underground facilities where operational continuity and security compliance are paramount.
Our rope access division provides IRATA-certified technicians who can work in challenging airport environments without the airspace restrictions and operational disruption associated with traditional access methods. This capability proves essential for terminal façade works, control tower glazing, and pier building projects where conventional scaffolding would interfere with aircraft movements or passenger flows. We coordinate closely with airport operations teams to schedule works during optimal windows whilst maintaining security protocols.
Technical specification support helps clients navigate the complex requirements of ASIAD guidance, Building Regulations, and aviation authority standards. We work with architects, security consultants, and airport operators to develop glazing solutions that balance security performance, operational needs, and architectural vision. Our specification process includes:
This comprehensive approach ensures solutions meet both immediate security requirements and long-term operational needs.
Emergency response capabilities address the 24/7 nature of airport operations. Security glazing failures from attempted breaches, accidental impacts, or extreme weather require rapid response to maintain operational security. Our emergency make-safe service provides immediate attendance with temporary security measures followed by permanent repairs using specification-compliant materials. This minimises security breaches and ensures compliance with aviation authority requirements.
